Specifications
Contents
Burson Conductor 3 Specifications
Input impedance: 40 KOhms Conductor V3 Ref.
Model # R180 USB Cable
Frequency response: ± 1 dB 0 – 58Khz Remote Control Warranty Card
THD: <0.0015% RCA Cable 24V Power Unit
Output impedance(Headphone Amp):0.5 Ohm Power Cable
Output impedance (Pre Out / DAC Out): 1 Ohm / 25 Ohm
General Inputs
2 x RCA line-level input, USB, Optical Toslink, BlueTooth 5.0, microphone
Weight: app. 5 kg
Outputs: 1 x RCA Pre Amp, 1 X Line Level DAC Out, 2 x 6.3mm Headphone Jack
Dimensions: 255mm x 270mm x 70mm
Impedance (Headphone Jack)
Power Signal to Noise Ratio Separation
16 Ohm 7.5W 95db 99%
32 Ohm 5W 97db 99%
100 Ohm 1.75W 94db 99%
150 Ohm 1.16W 95db 99%
300 Ohm 0.58W 95db 99.5%
DAC Specs
Asynchronous Isochronous USB Spec
Channel Separation: 142 dB @ 1KHz, 135 dB @ 20KHz Desktop OS: Windows XP, 7, 8, 10 Mac OSX THD+N: 0.0005% @ 1KHz, 0dBFS Desktop OS: iOS* , Android (OTG support)
COAX & Toslink / SPDIF : up to 24bit 192K
PCM Support: PCM 768kHz @ 16, 24 or 32bits
Native DSD: Native DSD 64 / 128 / 256 / 512
Bluetooth Input
Bluetooth 5.0 aptX HD (Qualcomm CSR8675) DSD over PCM: DoP64 / DoP128 / DoP256/Dop512
